VX-920/-920E VHF series Service Manual
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
Main Unit
Parts List
R 1023 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A C1
R 1024 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- A A3
R 1025 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B2
R 1026 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B2
R 1027 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- A C1
R 1028 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B1
R 1029 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A B2
R 1030 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A B2
R 1031 CHIP RES. 0.33 1/8W 10% RMC1/8 R33KTP J24219001 1- A B3
R 1032 CHIP RES. 0.33 1/8W 10% RMC1/8 R33KTP J24219001 1- A B3
R 1033 CHIP RES. 0.33 1/8W 10% RMC1/8 R33KTP J24219001 1- A B3
R 1034 CHIP RES. 8.2k 1/16W 5% RMC1/16S 822JTH J24189036 1- A B1
R 1035 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- A B2
R 1036 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- A C1
R 1037 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B1
R 1038 CHIP RES. 33 k 1/16W 5% RMC1/16S 333JTH J24189043 1- A G2
R 1039 CHIP RES. 1.5M 1/16W 5% RMC1/16S 155JTH J24189063 1- A C1
R 1040 CHIP RES. 220k 1/16W 0.5% MCR01MZPD2203 J24189389 1- A B3
R 1041 CHIP RES. 220k 1/16W 0.5% MCR01MZPD2203 J24189389 1- A B3
R 1042 CHIP RES.
68k 1/16W 5% RMC1/16S 683JTH J24189047 1- A G2
R 1043 CHIP RES. 220k 1/16W 0.5% MCR01MZPD2203 J24189389 1- A B3
R 1044 CHIP RES. 220k 1/16W 0.5% MCR01MZPD2203 J24189389 1- A B3
R 1045 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- B h2
R 1046 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- B h1
R 1047 CHIP RES. 22 k 1/16W 5% RMC1/16S 223JTH J24189041 1- A C1
R 1048 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- A D1
R 1049 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C1
R 1050 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A B2
R 1052 CHIP RES. 270k 1/16W 0.5% MCR01MZPD2703 J24189329 1- A B3
R 1053 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A B2
R 1055 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B g3
R 1056 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- A B3
R 1057 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- A A3
R 1058 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B g2
R 1059 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- A D1
R 1060 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C2
R 1061 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1 A D3
R 1061 CHIP RES. 27 k 1/16W 5% RMC1/16S 273JTH J24189042 2 A D3
R 1062 CHIP RES. 4. 7 1/16W 5% RMC1/16S 4R7JTH J24189066 1- A B2
R 1064 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A H1
R 1065 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D1
R 1066 CHIP RES. 2. 7 1/10W 5% RMC1/10T 2R7J J24205279 1- A C2
R 1067 CHIP RES. 2. 7 1/10W 5% RMC1/10T 2R7J J24205279 1- A C2
R 1068 CHIP RES. 18 k 1/16W 5% RMC1/16S 183JTH J24189040 1- A H1
R 1069 CHIP RES. 47 0 1/16W 5% RMC1/16S 471JTH J24189021 1- A C3
R 1069 CHIP RES. 33 0 1/16W 5% RMC1/16S 331JTH J24189019 3- A C3
R 1069 CHIP RES. 47 0 1/16W 5% RMC1/16S 471JTH J24189021 18- A C3
R 1070 CHIP RES. 15 0 1/16W 5% RMC1/16S 151JTH J24189015 1- A D3
R 1071 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A B2
R 1072 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B g2
R 1073 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A B2
R 1074 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- A B3
R 1075 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- A B3
R 1076 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A D3
R 1076 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 3- A D3
R 1077 CHIP RES. 270k 1/16W 0.5% MCR01MZPD2703 J24189329 1- A B3
R 1078 CHIP RES. 4. 7 1/16W 5% RMC1/16S 4R7JTH J24189066 1- A B2
R 1079 CHIP RES. 33 0 1/4W 5% RMC1/4 331JATP J24245331 5-24 B e3
R 1080 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B2
R 1081 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- A A3
R 1083 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B3
