VX-920/-920E VHF series Service Manual
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
Main Unit
Parts List
R 1084 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- A H3
R 1085 CHIP RES. 56 k 1/16W 5% RMC1/16S 563JTH J24189046 1- A B3
R 1086 CHIP RES. 39 k 1/16W 5% RMC1/16S 393JTH J24189044 1- A H3
R 1087 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A C2
R 1089 CHIP RES. 15 k 1/16W 5% RMC1/16S 153JTH J24189039 1- B e2
R 1090 CHIP RES. 120k 1/16W 5% RMC1/16S 124JTH J24189050 1- A H3
R 1091 CHIP RES. 82 0 1/16W 5% RMC1/16S 821JTH J24189024 1- B g2
R 1093 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B3
R 1094 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A B3
R 1095 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- A H3
R 1097 CHIP RES. 22 k 1/16W 5% RMC1/16S 223JTH J24189041 1- B h2
R 1098 CHIP RES. 56 k 1/16W 5% RMC1/16S 563JTH J24189046 1- A B4
R 1099 CHIP RES. 180k 1/16W 5% RMC1/16S 184JTH J24189052 1- A B4
R 1100 CHIP RES. 39 0 1/16W 5% RMC1/16S 391JTH J24189020 1- A D3
R 1100 CHIP RES. 22 0 1/16W 5% RMC1/16S 221JTH J24189017 3 A D3
R 1100 CHIP RES. 39 0 1/16W 5% RMC1/16S 391JTH J24189020 4-21 A D3
R 1101 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1-2 A D3
R 1102 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B h2
R 1103 CHIP RES. 33 k 1/16W 5% RMC1/16S 333JTH J24189043 1- A B4
R 1104 CHIP RES. 12 k 1/16W 5% RMC1/16S 123JTH J24189038 1- A G2
R 1105 CHIP RES. 220k
1/16W 5% RMC1/16S 224JTH J24189053 1- A B4
R 1106 CHIP RES. 33 0 1/16W 5% RMC1/16S 331JTH J24189019 1- B e3
R 1107 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1 A D3
R 1107 CHIP RES. 8.2k 1/16W 5% RMC1/16S 822JTH J24189036 2 A D3
R 1107 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 3 A D3
R 1107 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 4- A D3
R 1108 CHIP RES. 22 0 1/16W 5% RMC1/16S 221JTH J24189017 1- B h2
R 1110 CHIP RES. 56 k 1/16W 5% RMC1/16S 563JTH J24189046 1- A B4
R 1111 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A G3
R 1113 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- A G3
R 1114 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- A B4
R 1115 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- A H2
R 1117 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A H1
R 1120 CHIP RES. 33 0 1/16W 5% RMC1/16S 331JTH J24189019 1- A G3
R 1121 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- A G3
R 1122 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- A G2
R 1123 CHIP RES. 3.9k 1/16W 5% RMC1/16S 392JTH J24189032 1 A D3
R 1123 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 2 A D3
R 1123 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 3- A D3
R 1124 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A B3
R 1125 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- A G3
R 1126 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A G3
R 1127 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A G3
R 1128 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- A H1
R 1129 CHIP RES. 56 k 1/16W 5% RMC1/16S 563JTH J24189046 1- A G3
R 1130 CHIP RES. 12 k 1/16W 5% RMC1/16S 123JTH J24189038 1- A B3
R 1131 CHIP RES. 68 0 1/16W 5% RMC1/16S 681JTH J24189023 1- A G3
R 1132 CHIP RES. 8.2k 1/16W 5% RMC1/16S 822JTH J24189036 1- A G3
R 1133 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A G3
R 1134 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A G3
R 1135 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B g1
R 1136 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A B3
R 1137 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A D3
R 1138 CHIP RES. 1.2M 1/16W 5% RMC1/16S 125JTH J24189062 1- A E3
R 1139 CHIP RES. 22 k 1/16W 5% RMC1/16S 223JTH J24189041 1- A B3
R 1140 CHIP RES. 1.2k 1/16W 5% RMC1/16S 122JTH J24189026 1- A G3
R 1141 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- A G3
R 1142 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- A G3
R 1143 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- B e3
R 1144 CHIP RES. 10 0 1/16W 5% RMC1/16S 101JTH J24189013 1- B d3
R 1144 CHIP RES. 82 1/16W 5% RMC1/16S 820JTH J24189012 4 B d3
