VX-920/-920E VHF series Service Manual
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
Main Unit
Parts List
R 1144 CHIP RES. 82 1/16W 5% RMC1/16S 820JTH J24189012 5- B d3
R 1144 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 25- B d3
R 1145 CHIP RES. 56 0 1/16W 5% RMC1/16S 561JTH J24189022 1- A G3
R 1146 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- A G3
R 1147 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- A H3
R 1148 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B3
R 1150 CHIP RES. 22 k 1/16W 5% RMC1/16S 223JTH J24189041 1- A F3
R 1151 CHIP RES. 22 k 1/16W 5% RMC1/16S 223JTH J24189041 1- A F3
R 1152 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B g1
R 1153 CHIP RES. 820k 1/16W 5% RMC1/16S 824JTH J24189060 1- A E3
R 1154 CHIP RES. 22 k 1/16W 5% RMC1/16S 223JTH J24189041 1- A B3
R 1155 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- B d3
R 1156 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- B d3
R 1157 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A E3
R 1158 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A E3
R 1159 CHIP RES. 56 k 1/16W 5% RMC1/16S 563JTH J24189046 1- A G3
R 1160 CHIP RES. 56 0 1/16W 5% RMC1/16S 561JTH J24189022 1- A G4
R 1163 CHIP RES. 680k 1/16W 5% RMC1/16S 684JTH J24189059 1- A E3
R 1163 CHIP RES. 820k 1/16W 5% RMC1/16S 824JTH J24189060 35- A E3
R 1164 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B3
R 1165 CHIP RES. 330k
1/16W 5% RMC1/16S 334JTH J24189055 1- B a1
R 1166 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A C2
R 1167 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B a1
R 1168 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B a3
R 1169 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- A F3
R 1171 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- A E2
R 1172 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B a1
R 1173 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- A H4
R 1174 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B a3
R 1176 CHIP RES. 47 0 1/16W 5% RMC1/16S 471JTH J24189021 1- B f2
R 1176 CHIP RES. 56 0 1/16W 5% RMC1/16S 561JTH J24189022 4- B f2
R 1177 CHIP RES. 82 k 1/16W 5% RMC1/16S 823JTH J24189048 1- A D1
R 1178 CHIP RES. 56 k 1/16W 5% RMC1/16S 563JTH J24189046 1- A D2
R 1179 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D2
R 1180 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B a1
R 1181 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B a3
R 1182 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A H3
R 1183 CHIP RES. 33 0 1/16W 5% RMC1/16S 331JTH J24189019 1- B f2
R 1184 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A H4
R 1185 CHIP RES. 82 0 1/16W 5% RMC1/16S 821JTH J24189024 1- A G4
R 1186 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b3
R 1187 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b3
R 1188 CHIP RES. 56 k 1/16W 5% RMC1/16S 563JTH J24189046 1- A G3
R 1189 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B a3
R 1191 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B g1
R 1193 CHIP RES. 270k 1/16W 5% RMC1/16S 274JTH J24189054 1- A D2
R 1194 CHIP RES. 56 k 1/16W 5% RMC1/16S 563JTH J24189046 1- B a3
R 1195 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B a1
R 1196 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b3
R 1199 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A G3
R 1200 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- A G3
R 1201 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B f1
R 1202 CHIP RES. 22 0 1/16W 5% RMC1/16S 221JTH J24189017 1- B f1
R 1203 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B a1
R 1204 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- A H3
R 1205 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A D2
R 1206 CHIP RES. 22 k 1/16W 5% RMC1/16S 223JTH J24189041 1- B e2
R 1207 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- B c1
R 1208 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B a1
R 1209 CHIP RES. 3.9k 1/16W 5% RMC1/16S 392JTH J24189032 1- B b3
R 1210 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B a3
