VX-920/-920E VHF series Service Manual
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
SRX-3 Unit (Option)
Parts List
C 4068 CHIP CAP. 8pF 5 0V CH GRM1552C1H8R0DZ01D K22178210 1- B
C 4070 CHIP CAP. 2pF 5 0V CK GRM1554C1H2R0CZ01D K22178204 1- B
C 4071 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B
C 4072 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B
C 4073 CHIP CAP. 10pF 50V CH GRM1552C1H100JZ01D K22178212 1- B
C 4074 CHIP CAP. 3pF 50V CJ GRP1553C1H3R0CZ01E K22178205 1- B
C 4075 CHIP CAP. 8pF 5 0V CH GRM1552C1H8R0DZ01D K22178210 1- B
C 4076 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B
C 4077 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B
C 4079 CHIP CAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1 B
C 4082 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B
C 4083 CHIP CAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 2-
D 4001 DIODE 1SV323(TPH3.F) G2071006 1- B
D 4002 DIODE 1SV323(TPH3.F) G2071006 1- B
D 4003 DIODE 1SV323(TPH3.F) G2071006 1- B
D 4004 DIODE 1SV323(TPH3.F) G2071006 1- B
D 4005 DIODE 1SV323(TPH3.F) G2071006 1- B
D 4006 DIODE 1SV323(TPH3.F) G2071006 1- B
D 4007 DIODE 1SS400G T2R G2070934 1- B
D 4008 DIODE 1SV323(TPH3.F) G2071006 1- B
D 4009 DIODE 1SV323(TPH3.F) G2071006 1- B
J 4002 CONNECTOR AXN420C530P P0091090 1 A
J 4002 CONNECTOR AXN420030S P0091399 2- A
L 4002 CHIP COIL 0.0082uH LQW2BHN8N2D03L L1690608 1- B
L 4003 CHIP COIL 0.0082uH LQW2BHN8N2D03L L1690608 1- B
L 4004 COIL 0.009uH AS050325-9R0NK L0022612 1- B
L 4005 COIL 0.014uH AS050425-14NJ L0022827 1- B
L 4006 M.RFC 0.22uH ELJ-NDR22JF L1690628 1- B
L 4007 M.RFC 0.22uH HK1608 R22J-T L1690940 1- B
L 4008 COIL 0.014uH AS050425-14NJ L0022827 1- B
L 4009 COIL 0.025uH AS030521-25NK L0022585 1- B
L 4010 M.RFC 0.22uH HK1608 R22J-T L1690940 1- B
L 4011 M.RFC 0.027uH HK1608 27NJ-T L1690521 1- B
L 4012 M.RFC 0.22uH HK1608 R22J-T L1690940 1- B
L 4013 M.RFC 0.22uH HK1608 R22J-T L1690940 1- B
L 4014 M.RFC 0.027uH HK1608 27NJ-T L1690521 1- B
L 4015 M.RFC 0.33uH 2% C1608CB-R33G-RF L1691106 1- B
L 4016 M.RFC 0.027uH HK1608 27NJ-T L1690521 1- B
L 4017 M.RFC 0.22uH HK1608 R22J-T L1690940 1- B
L 4018 COIL 0.014uH AS050425-14NJ L0022827 1- B
L 4019 M.RFC 0.022uH HK1608 22NJ-T L1690520 1- B
L 4020 M.RFC 0.027uH HK1608 27NJ-T L1690521 1- B
L 4021 COIL 0.014uH AS050425-14NJ L0022827 1- B
L 4022 M.RFC 0.033uH HK1608 33NJ-T L1690522 1- B
L 4023 M.RFC 0.033uH HK1608 33NJ-T L1690522 1- B
L 4024 M.RFC 0.027uH HK1608 27NJ-T L1690521 1- B
L 4025 M.RFC 0.082uH HK1608 82NJ-T L1690527 1- B
L 4026 M.RFC 0.056uH HK1608 56NJ-T L1690525 1- B
L 4027 CHIP COIL 0.018uH LQW2BHN18NJ03L L1690612 1 B
L 4028 M.RFC 0.018uH HK1005 18NJ-T L1691105 2-
P 4001 WIRE ASSY U.FL-LP-040 L=50MM T9207085 1-
Q 4001 IC TC4S66F(TE85R.F) G1090893 1- B
Q 4002 TRANSISTOR RT1P441U-T11-1 G3070248 1 B
Q 4003 TRANSISTOR UNR911FJ0L G3070349 1- B
Q 4004 TRANSISTOR 2SC4617 TL R G3346178R 1- B
Q 4005 FET 2SK508-T2B K52 A G3805087B 1- B
Q 4006 TRANSISTOR 2SC5226-4/5-TL G3352268Z 1- B
Q 4007 TRANSISTOR 2SC5226-4-TL G3352268D 1- B
Q 4008 FET 3SK320(TE85L) G4803208 1- B
Q 4009 TRANSISTOR 2SC5226-4-TL G3352268D 1- B
