59
VX-920/-920E VHF series Service Manual
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
SRX-3 Unit (Option)
Parts List
Q 4010 TRANSISTOR 2SC5226-4-TL G3352268D 1- B
Q 4011 TRANSISTOR RT1N441U-T11-1 G3070247 1- B
Q 4011 TRANSISTOR DTC144EE TL G3070075 38- B
Q 4012 TRANSISTOR RT1N441U-T11-1 G3070247 1- B
Q 4012 TRANSISTOR DTC144EE TL G3070075 38- B
R 4001 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1 B
R 4003 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B
R 4004 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- B
R 4005 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B
R 4006 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B
R 4007 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B
R 4008 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B
R 4009 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B
R 4010 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- B
R 4011 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B
R 4012 CHIP RES. 10 0 1/16W 5% RMC1/16S 101JTH J24189013 1- B
R 4013 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B
R 4014 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B
R 4016 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- B
R 4017 CHIP RES. 22 0 1/16W 5% RMC1/16S 221JTH J24189017 1- B
R 4018 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- B
R 4020 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B
R 4021 CHIP RES. 33 k 1/16W 5% RMC1/16S 333JTH J24189043 1- B
R 4023 CHIP RES. 56 0 1/16W 5% RMC1/16S 561JTH J24189022 1- B
R 4024 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B
R 4025 CHIP RES. 10 0 1/16W 5% RMC1/16S 101JTH J24189013 1- B
R 4026 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B
R 4027 CHIP RES. 47 0 1/16W 5% RMC1/16S 471JTH J24189021 1- B
R 4028 CHIP RES. 82 k 1/16W 5% RMC1/16S 823JTH J24189048 1- B
R 4029 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B
R 4030 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- B
R 4031 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B
R 4032 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B
R 4033 CHIP RES. 22 0 1/16W 5% RMC1/16S 221JTH J24189017 1- B
R 4034 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B
R 4035 CHIP RES. 47 k 1/16W 5% RMC1/16S 473JTH J24189045 1- B
R 4036 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B
R 4037 CHIP RES. 27 0 1/16W 5% RMC1/16S 271JTH J24189018 1- B
R 4038 CHIP RES. 10 k 1/16W 5% RMC1/16S 103JTH J24189037 1- B
R 4039 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B
SHIELD CASE (SUB) RA0697700 1-
