9.2 Electrical Conguration
Problem Solution
Nuisance trips • Verify with the manufacturer of the electrical device
that you’ve used the correct circuit breaker value.
Do not increase the CB value over what the wire can
support. Use these for guidelines:
14 gauge wire – 15A max
18 gauge wire – 10A max
20 gauge wire – 5 A max
• If nuisance trips persist, contact Vertical Power
Support.
9.3 Trim faults
Problem Solution
Trim faults at
power on
The trim is designed to fault if any of the trim switches
are on at power on.
• Verify that none of the trim switch input wires are
shorted to ground.
• Verify that none of the trim input switches are closed.
Cannot clear a
trim fault
• A trim switch input line is still grounded. You must
un-ground the input and re-cycle power to the
system.
9.4 “Cannot Connect” error when using VP-X Congurator
Please see the Congurator Release Notes document for troubleshooting
instructions. The release notes are available on the Vertical Power website at
www.verticalpower.com under Help and then Software.
