Vertical Power VP-X Pro - Appendix A3 - J2 Connector Wiring

Page 75
VP-X Installation and Operating Manual
Rev. D (August 5, 2020)
Appendix A3 – J2 Connector Wiring
VP-X J2
Female
Male
REV A
1
2
3
4
5
6
7
8
9
10
11
12
14
15
16
17
18
19
Switch input 1
Switch input 2
Switch input 3
Switch input 4
Switch input 5
Switch input 6
Switch input 7
Switch input 8
Switch input 9
Switch input 10
Starter annun input
Aux batt voltage input
Flap up switch
Flap down switch
Roll trim left input
Roll trim right input
Pitch trim up input
Pitch trim dn input
Use wire M22759/16-22 (22 AWG Tefzel)
6
Resistor. See manual.
1
6
6
6
From switched side of starter contactor
From aux battery positive terminal
1
