Vertical Power VP-X Pro - Appendix A - Pinout Diagram

Page 72
VP-X Installation and Operating Manual
Rev. D (August 5, 2020)
Appendix A – Pinout Diagram
System Name Bank Amps Range Physical Pin I/O
Flap B 1-10 J12-5 & 6 O
Starter A or B 1-10 J10-1 O
EFIS A 1-5 J12-9 O
Field_Pri A 1-5 J12-11 O
5A-1 A 1-5 J8-1 O
5A-2 A 1-5 J8-3 O
5A-3 A 1-5 J8-4 O
5A-4 A 1-5 J8-5 O
5A-5 B 1-5 J8-6 O
5A-6 B 1-5 J8-7 O
5A-7 B 1-5 J8-8 O
5A-8 B 1-5 J10-2 O
5A-9 B 1-5 J10-4 O
5A-10 B 1-5 J10-7 O
5A-11 B 1-5 J10-8 O
5A-12 B 1-5 J10-10 O
5A-13 A 1-5 J12-8 O
10A-1 A 1-10 J8-2 O
10A-2 B 1-10 J10-3 O
10A-3 B 1-10 J10-5 O
10A-4 A 1-10 J12-1 O
10A-5 A 1-10 J12-3 O
10A-6 A 1-10 J12-7 O
15A-1 B 1-15 J10-6 O
15A-2 A 1-15 J12-2 O
15A-3 A 1-15 J12-12 O
3A-1 A 1-3 J12-10 O
2A-1 A 1-2 J1-1 O
2A-2 A 1-2 J1-2 O
Trim Roll A 1 J1-6/7 O
Trim Pitch A and B 1 J1-11/12 O
S1 A or B J2-1 I
S2 A or B J2-2 I
S3 A or B J2-3 I
S4 A or B J2-4 I
S5 A or B J2-5 I
S6 A or B J2-6 I
S7 A or B J2-7 I
S8 A or B J2-8 I
S9 A or B J2-9 I
S10 A or B J2-10 I
Other I/O
Function Pin I/O
Aux batt voltage J2-12 I
Starter annunciator input J2-11 I
Roll trim position J1-5 I
Pitch trim position J1-10 I
Serial TX J1-20 O
Serial RX J1-22 I
Flap Up J2-14 I
Flap Dn J2-15 I
Roll Trim L J2-16 I
Roll Trim R J2-17 I
Pitch Trim U J2-18 I
Pitch Trim D J2-19 I
