KEY COMBINATION DESCRIPTION
STANDARD
SWITCHES
VERSION
10020715
VERSION
10300915
VERSION
10020316
OR
HIGHER
KVM KM
MINI-
MATRIX
L Ctrl L Ctrl F11 F2 Load preset 2 N Y Y Y N Y N
L Ctrl L Ctrl F11 F3 Load preset 3 N Y Y Y N Y N
L Ctrl L Ctrl F11 F4 Load preset 4 N Y Y Y N Y N
L Ctrl L Ctrl F11 F5 Load preset 5 N Y Y Y N Y N
L Ctrl L Ctrl F11 F6 Load preset 6 N Y Y Y N Y N
L Ctrl L Ctrl F11 F7 Load preset 7 N Y Y Y N Y N
L Ctrl L Ctrl F11 F8 Load preset 8 N Y Y Y N Y N
L Ctrl L Ctrl F11 F9 Load preset 9 N Y Y Y N Y N
L Ctrl L Ctrl F11 F10 Load preset 10 N Y Y Y N Y N
L Ctrl L Ctrl F11 1-3 1-0 Load preset 1-3 or 1-0 N Y Y Y N Y N
L Ctrl L Ctrl F11 F12
Load previously
loaded preset
N Y Y Y N Y N
L Ctrl L Ctrl F11 L 1 Load layout 1 N N N Y N N Y
L Ctrl L Ctrl F11 L 2 Load layout 2 N N N Y N N Y
L Ctrl L Ctrl F11 L 3 Load layout 3 N N N Y N N Y
L Ctrl L Ctrl F11 L 4 Load layout 4 N N N Y N N Y
L Ctrl L Ctrl F11 L 5 Load layout 5 N N N Y N N Y
L Ctrl L Ctrl F11 L 6 Load layout 6 N N N Y N N Y
L Ctrl L Ctrl F1 1-4
Display channel 1-4 on
monitor 1
Y N N Y N N Y
L Ctrl L Ctrl F2 1-4
Display channel 1-4 on
monitor 2
Y N N Y N N Y
1
You must press and hold this keyboard shortcut to execute the command.
2
This command is only available when the switch is in KMmode.
Table 2.12 KM Keyboard Shortcuts (continued)
2.4 KM Configuration
The KMconfiguration utility is a web-based tool that allows system administrators to define custom
monitor setups in a KMconfiguration file. The file is saved with the .kmc extension. When configuring a
KMswitch using a KM configuration file, you must be logged in to the switch as administrator.
