Console Display Type Dual DVI & DP 1.2 Monitors Dual Dual-link DVI-I & HDMI 1.4 Monitors
Computers Audio/USB Audio/USB/DPP Audio/USB Audio/USB/DPP
2 Cybex SC 920XP - Cybex SC 920XD -
4 - Cybex SC 945XP - Cybex SC 945XD
Table A.5 Single/Dual Link DVI-I (2560 x 1600) & DisplayPort 1.2 (4K UHD 3840 x 2160 @ 30 Hz)
Computers
Computers Audio/USB Audio/USB/DPP
2 Cybex SCKM 120 Cybex SCKM 125
4 - Cybex SCKM 145
Table A.6 Secure Keyboard and Mouse Switches (no video)
Computers Width (in/mm) Depth (in/mm)
SC 800 Single-Head SC 900 Dual-Head
Height (in/mm) Weight (lb/kg) Height (in/mm) Weight (lb/kg)
2 7.0 / 178 2.4 / 61 1.7 / 43 1.0 / 0.5 2.2 / 56 1.5 / 0.7
4 13.7 / 348 5.0 / 127 1.7 / 43 3.0 / 1.5 2.2 / 56 3.7 / 1.9
8 17.3 / 439 7.3 / 185 1.7 / 43 5.4 / 2.5 2.2 / 56 6.8 / 3.1
Table A.7 Dimensions and Weights
Series Operating Temperature Humidity Storage Temperature
All Series
32° to 104°F
0° to 40°C
0-80% RH, non-condensing
-4° to 140°F
-20° to 60°C
Table A.8 Environmental Conditions
Computers Power AC Input Voltage
2 12V DC 1.5A External Power Adaptor
100 to 240V AC 50/60 Hz4 35W Max Internal Power Supply
8 45W Max Internal Power Supply
Table A.9 Electrical Power
Vertiv™ | Cybex™ SC Switching System Installer/User Guide
38
