Product Overview
Vertiv | Liebert CRD10 | User Manual 2
Refer Figure 1-2 for the nameplate description of the CRD10 model:
UL Model:
POS.
DESCRIPTION
POS.
DESCRIPTION
1
Unit defined by 6 digits
10
Rated load current of compressor
2
Model defined by 12 digits
11
Refrigerant Amount Charged on site
3
Supply Power
12
Discharge Side Excessive Operating Pressure
4
Cooling capacity
13
Suction Side Excessive Operating Pressure
5
Indoor fan power in total
14
Minimum Circuit Amps
6
Indoor fan full load current in total
15
Maximum Overcurrent Protection
7
Outdoor fan power in total
16
Equipped with outdoor model
8
Outdoor fan full load current in total
17
Serial Number
9
Locked rotor current of compressor
CE Model:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1
3
4
6
7
8
9
10
2
5
11
12
13
14
15
16
17
18
