Mechanical Installation
Vertiv | Liebert CRD10 | User Manual 31
3.3.3
Front Air outlet Locations and Dimensions
The location and dimensions of the air outlet at the front are shown in Figure 3-5.
Figure 3-5 Front Air Outlet Locations & Dimensions
300mm
[11.8in.]
250mm
[9.8in.]
1895mm
[74.6in.]
2000mm
[78.7in.]
