REV : 0
REV DATE : 3/18
DPN004706
Page :2 /4
DP500 PERIMETER AND ROOFTOP UNIT
Form No.: DPN001040_REV4
EQUIPMENT FLOOR PLAN
LIEBERT DSE
Notes:
1. Grating is Removable.
2. C4 x 5.4 Frame Member.
3. 4x2 Tubing Frame Member.
Grating Level
(Top View)
Main EP Box
ATS (Optional)
2
2
2
2
2
2
3
PRE 1
PRE 2
Compressor
Cabinet 2
Compressor
Cabinet 1
Recommended Area
For Utility Feed
