21
 05: Acceptable high voltage for bypass mode
Interface
Setting
Parameter 2: Set the acceptable high voltage for bypass mode.
Setting range is from 231V to 276V and the default value is
264V.
 06: Acceptable low frequency for bypass mode
Interface
Setting
Parameter 2: Set the acceptable low frequency for bypass
mode.
50 Hz system: Setting range is from 46.0Hz to 49.0Hz.
60 Hz system: Setting range is from 56.0Hz to 59.0Hz.
The default value is 46.0Hz/56.0Hz.
 07: Acceptable high frequency for bypass mode
Interface
Setting
Parameter 2: Set the acceptable high frequency for bypass.
50 Hz: Setting range is from 51.0Hz to 54.0 Hz.
60 Hz: Setting range is from 61.0Hz to 64.0Hz.
The default value is 54.0Hz/64.0Hz.
 08: ECO mode enable/disable
Interface
Setting
Parameter 2: Enable or disable ECO function. You may choose
following two options:
ENA: enable ECO function;
DIS:: disable ECO function;
If ECO function is disabled, voltage range and frequency range
for ECO mode still can be set, but it is meaningless unless the
ECO function is enabled.
 09: Acceptable low voltage for ECO mode
Interface
Setting
Parameter 2: Low voltage point in ECO mode. The setting range
is from -5% to -10% of the nominal voltage.
