6. Specifications
MODEL
GXT-MT+ 10KVA LX (3x3) L
CAPACITY
10000VA / 9000W
INPUT
Voltage
Range
Low Line Loss
110 VAC(Ph-N) ± 3 % at 50% Load
176 VAC(Ph-N) ± 3 % at 100% Load
Low Line Comeback
Low Line Loss Voltage + 10V
High Line Loss
300 VAC(L-N) ± 3 % at 50% Load
276 VAC(L-N) ± 3 % at 100% Load
High Line Comeback
High Line Loss Voltage - 10V
Frequency Range
46Hz ~ 54 Hz @ 50Hz system
56Hz ~ 64 Hz @ 60Hz system
Phase
Three phase with Neutral
Power Factor
≧ 0.99 at 100% Load
OUTPUT
Phase
Three Phase with Neutral
Output voltage
3 x 400 VAC (3Ph+N)
AC Voltage Regulation
± 1%
Frequency Range
(Synchronized Range)
46Hz ~ 54 Hz @ 50Hz system
56Hz ~ 64 Hz @ 60Hz system
Frequency Range (Batt. Mode)
50 Hz ± 0.1 Hz or 60Hz ± 0.1 Hz
Overload
AC mode
100%~110%: 10min
110%~130%: 1min
>130% : 1sec
Battery mode
100%~110%: 30sec
110%~130%: 10sec
>130% : 1sec
Current Crest Ratio
3:1 max
Harmonic Distortion
≦ 2 % @ 100% Linear Load; ≦ 5 % @ 100% Non-linear Load
Transfer
Time
Line Battery
0 ms
Inverter Bypass
0 ms (When phase lock fails, <4ms interruption occurs from inverter to bypass)
Inverter ECO
<10 ms
EFFICIENCY
AC mode
> 89%
Battery Mode
> 86%
BATTERY
Type
Depending on applications
Numbers
18 - 20
Recharge Time
Depending on external battery capacity
Charging Current
12.0 A ± 10% (max.)
Charging Voltage
273 VDC ± 1%
PHYSICAL
Dimension, D X W X H (mm)
592X250X826
Net Weight (kgs)
38
ENVIRONMENT
Operation Temperature
0 ~ 40°C (the battery life will down when > 25°C)
Operation Humidity
<95 % and non-condensing
Operation Altitude*
<1000m
Acoustic Noise Level
Less than 60dB @ 1 Meter
MANAGEMENT
Smart RS-232 or USB
Supports Windows® 2000/2003/XP/Vista/2008, Windows® 7, Linux, Unix, and MAC
Optional SNMP
Power management from SNMP manager and web browser
*If the UPS is installed or used in a place where the altitude is above than 1000m, the output power must be derated one percent per 100m.
**Product specifications are subject to change without further notice.
