Table 3-4 Analog main menu ID significances
Sub Menu ID Significance Display Remarks
F00
The maximum pressure
between the pressure 1 and
pressure 2
0～44.2Bar Condensing pressure
888 Sensor fault
F01 Pressure 1
0～44.2Bar Condensing pressure
888 Sensor fault
F02 Pressure 2
0～44.2Bar Condensing pressure
888 Sensor fault
F03 Ambient temperature -41℃～106℃
-41
：The temperature
sensor is not connected
106
：Temperature sensor
short
-40
～105
：Ambient
temperature
F04 Output percentage 0～100 Rated frequency 50/60Hz
F05 State of enable signal
0 ON
1 OFF
F06 State of alarm
0 ON
1 OFF
Current alarm main menu interface
Press the ENT key to enter the current alarm submenu interface when the current main menu
interface shows ‘A--’ (the symbol of current alarm main menu). The switching operation
processes and orders of the current alarm submenu are shown in Figure 3-6, and the Current
alarm main menu ID significances are shown in Table 3-5.
