8. Installation
8.1 Overview
The unit is delivered fully assembled at the factory, including all the internal wiring.
The following operations must be done at the installation site:
Operation See ...
Position the unit at the nal location and x it on the oor or the
supporting structure
8.3 Location
8.4 Space Requirements
Connect the piping to the main unit 8.5 Piping
Connect the main switch to the electric power supply 8.6 Electrical Connections
8.2 Safety Instructions
WARNING
Only authorized personnel is allowed to do installation operations.
The authorized personnel must be properly trained and qualied, wear appropriate personal protective equipment
and use adequate tools.
CAUTION
Sharp edges, splinters and exposed fasteners.
Wear protective gloves before operating on the unit.
NOTICE
Improper handling can cause product damage.
8.3 Location
Condensers should be installed in a location o󰀨ering maximum security and access for maintenance.
The service area must be respected.
Avoid areas prone to heavy snow or ice accumulations.
The installation site must guarantee a su󰀩cient dispersion of the air to allow operation in even the severest conditions. Vertiv™
recommends that condensers to be installed in an area with clean air, away from loose dirt and foreign matter that might clog the
coil.
For roof installation, mount the condenser on suitable curbs or other supports in accordance with local rules.
Follow the installation arrows on the condenser for the installation.
Horizontal installation (vertical air ow):
• In order to allow su󰀩cent air through the unit and space for any eventual maintenance, The Service Area should be left free
of obstructions.
• With vertical air ow installation, a free area of at least 4 m above the condenser has to be guarantee for a correct air
circulation with the aim to avoid shot-cut from discharge to suction air side of condenser.
