Figure 6.5 Dimensions, indoor air-cooled condensing unit
Model #
Dimensions, in (mm)
Net Weight lb (kg)
A B C D
MC*24A
1- 7/16 (37) 11-7/16 (290) 1/2 (13) 20-7/16 (519)
230 (104)
MC*23A
MC*36A
240 (109)
MC*35A
Table 6.5 Dimensions and net weights, indoor air-cooled
condensing units
Vertiv | Liebert Mini-Mate2—2 and 3 ton Technical Data Manual | 26
