6 AIR-COOLED SYSTEMS—CAPACITIES AND DIMENSIONS
Evaporator Model
MMD24E or MMD24K MMD36E or MMD36K
Condensing Unit Type
PFH - Outdoor MCD - Indoor PFH - Outdoor MCD - Indoor
DX Evaporator- Net Capacity Data - kW (Btuh) @ High Speed CFM
80°F DB, 62.8°F WB (26.7°C
DB, 17.1°C WB) 38%RH
Total 6.70 (22,900) 6.50 (22,200) 9.90 (33,800) 9.35 (31,900)
Sensible 6.50 (22,200) 6.35 (21,700) 9.40 (32,100) 9.10 (31,000)
75°F DB, 61°F WB (23.9°C
DB, 16.1°C WB) 45%RH
Total 6.40 (21,800) 6.15 (20,900) 9.55 (32,500) 8.95 (30,600)
Sensible 5.70 (19,500) 5.60 (19,100) 8.30 (28,400) 8.05 (27,500)
72°F DB, 60°F WB (22.2°C
DB, 15.5°C WB) 50%RH
Total 6.20 (21,200) 5.95 (20,300) 9.30 (31,800) 8.75 (29,900)
Sensible 5.20 (17,800) 5.10 (17,400) 7.70 (26,200) 7.40 (25,300)
Fan Data - Evaporator
CFM (CMH) - High Speed 885 (1504) 1250 (2124)
CFM (CMH) - Low Speed 800 (1359) 1000 (1699)
Fan Motor, HP (W) 0.5 (0.38) 0.5 (0.38)
External Static Pressure, in (mm) water gauge 0.3 (8) 0.3 (8)
Evaporator Coil - Copper Tube/Aluminum Fin
Face Area, ft
2
(m
2
) 3.1 (0.29) 3.1 (0.29)
Coil Rows 3 3
Max Face Velocity ,fpm(m/s) 277 (1.4) 394 (2.0)
Unit Refrigerant Charge, oz. (kg) 7 (0.20) 7 (0.20)
Unit Operating Weight 225 (102) 225 (102)
Electric Reheat Capacity (Includes Fan Motor), kW
(Btuh)
Standard SCR Standard SCR
Input Voltage 208-1-60 4.7 (16040) 5.6 (19100) 4.7 (16040) 7.9 (27000)
Input Voltage 230-1-60 5.8 (19800) 6.8 (23200) 5.8 (19800) 9.5 (32400)
Input Voltage 277-1-60 6.3 (21500) 7.3 (24900) 6.3 (21500) 10.3 (35200)
Input Voltage 208-3-60
N/A
5.6 (19100) 7.9 (27000)
Input Voltage 230-3-60 6.8 (23200) 9.5 (32400)
Input Voltage 460-3-60 7.3 (24900) 10.3 (35200)
Humidifier Data - Steam Generator Type
Steam capacity, lb/hr (kg/hr) 4.3 (2.0) 4.3 (2.0)
Electrical Input Power, kW 1.5 1.5
Evaporator Connection Sizes
Liquid line Diameter - Aeroquip Coupling Size 3/8" - #6 Female 3/8" - #6 Female
Suction Line Diameter - Aeroquip Coupling Size 7/8" - #11 Female 7/8" - #11 Female
Humidfier Supply 1/4" OD Copper Compression Fitting
Evaporator/Condensate Drain 3/4" NPT-Female
MERV 8 Filter, External Filter Box, qty (1), Nom. Size,
in. (mm)
4x20x20 (102x508x508)
Table 6.1 Air-cooled data, 60Hz
