8 CHILLED WATER SYSTEMS—CAPACITIES AND
DIMENSIONS
CW Model, 50 & 60Hz
MMD40C/MMD39C
Net Capacity Data - kW (Btuh) based on 45°F (7.2°C) EWT & 10°F (5.6°C) temperature rise
80°F DB, 62.8°F WB (26.7°C DB, 17.1°C WB)
38%RH
Total 10.1 (34,600)
Sensible 9.40 (32,100)
Flow Rate, GPM (l/m) 7.2 (27.3)
Pressure Drop, ft. water (kPa) 13.1 (39.2)
75°F DB, 61°F WB (23.9°C DB, 16.1°C WB)
45%RH
Total 8.25 (28,200)
Sensible 7.60 (26,000)
Flow Rate, GPM (l/m) 5.9 (22.4)
Pressure Drop - ft. water (kPa) 9.3 (27.8)
72°F DB, 60°F WB (22.2°C DB, 15.5°C WB)
50%RH
Total 7.10 (24,200)
Sensible 6.50 (22,200)
Flow Rate, GPM (l/m) 5.2 (19.7)
Pressure Drop, ft. water (kPa) 7.2 (21.5)
Fan Data - Evaporator
CFM (CMH) 1250 (2124)
CFM (CMH), Low Speed
1000 (1699)
Fan Motor, hp (kW) 0.5 (0.38)
External Static Pressure, in (mm) water gauge 0.3 (8)
CW Coil - Copper Tube/Aluminum Fin
Face Area ft
2
(m
2
) 3.1 (0.29)
Coil Rows 3
Max Face Velocity, fpm (m/s) 391 (2.0)
Electric Reheat Capacity (Includes Fan Motor)-kW (Btuh)
Input Voltage 208-1-60 4.7 (16040)
Input Voltage 230-1-60 5.8 (19800)
Input Voltage 277-1-60 6.3 (21500)
Input Voltage 208-3-60 5.6 (19100)
Input Voltage 230-3-60 6.8 (23200)
Input Voltage 460-3-60 7.3 (24900)
Input Voltage-220-1-50 5.3 (18090)
Input Voltage-380-3-50 7.3 (24900)
Hot Water Reheat Coil - Copper Tube/Aluminum Fin
Capacity (with fan motor heat) using 180°F (82°C) EWT, kW (Btuh) 16.1 (54,900)
Flow Rate - GPM (l/m) 4.0 (15.2)
Pressure Drop, ft. water (kPa) 8.5 (25.4)
Table 8.1 Chilled water data, 60 and 50Hz
Vertiv | Liebert Mini-Mate2—2 and 3 ton Technical Data Manual | 39
