9 ELECTRICAL DATA
Base Evaporator Model
Number
208/230 - 1 Ph - 60Hz 277 - 1 Ph - 60Hz 208/230 - 3 Ph - 60Hz 460 - 3 Ph - 60Hz
MM*24E MM*36E MM*24E MM*36E MM*24E MM*36E MM*24E MM*36E
Cooling Only
FLA 2.8 2.8 2.3 2.3 — 2.8 — 1.4
WSA 3.5 3.5 2.9 2.9 — 3.5 — 1.8
OPD 15 15 15 15 — 15 — 15
with Electric Reheat
FLA 27.8 27.8 24.0 24.0 — 19.6 — 9.8
WSA 34.8 34.8 30.0 30.0 — 24.5 — 12.3
OPD 35 35 35 35 — 25 — 15
with SCR Reheat
4
FLA 32.0 44.5 27.6 38.4 — 26.9 — 13.5
WSA 40.0 55.6 34.5 48.0 — 33.6 — 16.9
OPD 45 60 35 50 — 35 — 20
with Humidifier
FLA 9.2 9.2 8.0 8.0 — 9.2 — 4.8
WSA 11.5 11.5 10.0 10.0 — 11.5 — 6.0
OPD 15 15 15 15 — 15 — 15
with Electric Reheat and Humidifier
FLA 34.2 34.2 29.7 29.7 — 26.0 — 13.2
WSA 42.8 42.8 37.1 37.1 — 32.5 — 16.5
OPD 45 45 40 40 — 35 — 20
with SCR Reheat
4
and Humidifier
FLA 38.4 50.9 33.3 44.1 — 33.3 — 16.9
WSA 48.0 63.6 41.6 55.1 — 41.6 — 21.1
OPD 50 70 45 60 — 45 — 25
* Specify disconnect or no disconnect
Notes:
1. Use MM*36E electrical data for MM*40C chilled water units
2. For units with Hot Water Reheat (available only on MM*40C units), use appropriate values from “Cooling only” or “with Humidifier”
categories.
3. Use MM*24E and MM*36E for MM*24K & MM*36K, respectively, except with SCR reheat.
4. SCR Reheat not available with MM*24K, MM*36K or MM*40C.
Table 9.1 Direct drive split system evaporator or chilled water unit electrical data, 60Hz
Vertiv | Liebert Mini-Mate2—2 and 3 ton Technical Data Manual | 45
