Base Evaporator
Model Number
208/230 - 1 Ph - 60Hz 277 - 1 Ph - 60Hz 208/230 - 3 Ph - 60Hz 460 - 3 Ph - 60Hz
MM*24E MM*36E MM*24E MM*36E MM*24E MM*36E MM*24E MM*36E
Cooling Only
FLA 9.2 9.2 6.4 6.4 — 4.8 — 2.1
WSA 11.5 11.5 8.0 8.0 — 6.0 — 2.6
OPD 20 20 15 15 — 15 — 15
with Electric Reheat
FLA 34.2 34.2 28.1 28.1 — 21.6 — 10.5
WSA 42.8 42.8 35.1 35.1 — 27.0 — 13.1
OPD 45 45 40 40 — 30 — 15
with SCR Reheat
5
FLA 38.4 50.9 31.7 42.5 — 28.9 — 14.2
WSA 48.0 63.6 39.6 53.1 — 36.1 — 17.8
OPD 50 70 40 60 — 40 — 20
with Humidifier
FLA 15.6 15.6 12.1 12.1 — 11.2 — 5.5
WSA 19.5 19.5 15.1 15.1 — 14.0 — 6.9
OPD 25 25 20 20 — 15 — 15
with Electric Reheat and Humidifier
FLA 40.6 40.6 33.8 33.8 — 28.0 — 13.9
WSA 50.8 50.8 42.3 42.3 — 35.0 — 17.4
OPD 60 60 45 45 — 40 — 20
with SCR Reheat
5
and Humidifier
FLA 44.8 57.3 37.4 48.2 — 35.3 — 17.6
WSA 56.0 71.6 46.8 60.3 — 44.1 — 22.0
OPD 60 80 50 70 — 45 — 25
* Specify disconnect or no disconnect
Notes:
1. Belt drive data includes externally mounted high static blower box, powered from unit.
2. Use MM*36E electrical data for MM*40C chilled water units.
3. For units with Hot Water Reheat (available only on MM*40C units), use appropriate values from “Cooling only” or “with Humidifier”
categories.
4. Use MM*24E and MM*36E for MM*24K & MM*36K, respectively, except with SCR reheat.
5. SCR Reheat not available with MM*24K, MM*36K or MM*40C.
Table 9.2 Belt drive split system evaporator or chilled water electrical data, with high static blower
box, 60Hz
Vertiv | Liebert Mini-Mate2—2 and 3 ton Technical Data Manual | 46
