Vertiv Liebert Mini-Mate2 MMD24E User Manual

Base Evaporator Model Number
220 - 1Ph - 50Hz 380/415 - 3Ph-50Hz
MM*35E MM*35E
Cooling Only
FLA 2.8 1.4
with Electric Reheat
FLA 27.8 11.1
with SCR Reheat
4
FLA 44.6 15.3
with Humidifier
FLA 9.2 5.1
with Electric Reheat and Humidifier
FLA 34.2 14.8
with SCR Reheat and Humidifier
4
FLA 50.9 19.0
* Specify disconnect or no disconnect
Notes:
1. Use MM*35E electrical data for MM*39C chilled water units.
2. For units with Hot Water Reheat (available only on MM*39C units), use appropriate values from “Cooling only” or “with
Humidifier” categories.
3. Use MM*35E for MM*35K, except with SCR reheat.
4. SCR Reheat not available with MM*35K or MM*39C.
Table 9.3 Direct drive split system evaporator or chilled water electrical data, 50Hz
220 - 1 Ph - 50Hz 380/415 - 3 Ph - 50Hz
Base Evaporator Model Number MM*35E MM*35E
Cooling Only
FLA 7.0 2.6
with Electric Reheat
FLA 32.0 12.3
with SCR Reheat
5
FLA 48.7 16.5
with Humidifier
Table 9.4 Belt drive split system evaporator or chilled water electrical data, 50Hz
Vertiv | Liebert Mini-Mate2—2 and 3 ton Technical Data Manual | 47
