220 - 1 Ph - 50Hz 380/415 - 3 Ph - 50Hz
Base Evaporator Model Number MM*35E MM*35E
FLA 13.4 6.3
with Electric Reheat and Humidifier
FLA 38.4 16.0
with SCR Reheat and Humidifier
5
FLA 55.1 20.2
* Specify disconnect or no disconnect
Notes:
1. Belt drive data includes externally mounted high static blower box, powered from unit.
2. Use MM*35E electrical data for MM*39C chilled water units.
3. For units with Hot Water Reheat (available only on MM*39C units), use appropriate values from “Cooling only” or “with
Humidifier” categories.
4. Use MM*35E for MM*35K, except with SCR reheat.
5. SCR Reheat not available with MM*35K or MM*39C.
Table 9.4 Belt drive split system evaporator or chilled water electrical data, 50Hz (continued)
Model
60Hz 50Hz
208/230-1ph-60Hz 277-1ph-60Hz 208/230-3ph-60Hz 460-3ph-60Hz 220-1ph-50Hz 380/415-3ph-50Hz
MC*24A MC*24A MC*24A MC*24A — —
FLA 14.3 12.7 — — 13.2 5.7
WSA 17.3 15.3 — — — —
OPD 25 25 — — N/A N/A
MC*36A MC*36A MC*36A MC*36A MC*35A MC*35A
FLA 20.8 16.6 15.7 7.8 20.1 7.8
WSA 25.1 20.2 18.7 9.4 — —
OPD 40 30 30 15 — —
MC*26W MC*26W MC*26W MC*26W — —
FLA 12.0 10.4 — — — —
WSA 15.0 13.0 — — — —
OPD 25 20 — — — —
MC*38W MC*38W MC*38W MC*38W MC*37W MC*37W
FLA 17.1 14.3 12.0 6.4 17.1 6.4
WSA 21.4 17.9 15.0 8.0 — —
OPD 35 30 25 15 — —
* Specify disconnect or no disconnect
Table 9.5 Indoor condensing unit electrical data, 60 and 50Hz
Vertiv | Liebert Mini-Mate2—2 and 3 ton Technical Data Manual | 48
