Vertiv Liebert Mini-Mate2 MMD24E User Manual

Evaporator Model
MMD24E or MMD24K MMD36E or MMD36K
Condensing Unit Type
PFH - Outdoor MCD - Indoor PFH - Outdoor MCD - Indoor
MERV 8 Filter, Air Distribution Plenum, qty (1), Nom.
Size-in. (mm)
4x16x25 (102x406x635)
Condensing Unit Model Number PFH027A-_L7 MCD24AL_H7 PFH037A-_L7 MCD36AL_H7
Condensing Unit Rating Conditions 95°F (35°C) Ambient
Coil Face Area ft
2
(m
2
) 4.1 (0.38) 4.6 (0.43) 7.7 (0.72) 4.6 (0.43)
Rows of Coil 2 2 2 3
CFM (CMH) 2200 (3738) 1000 (1698) 3000 (5097) 1430 (2429)
Motor Hp (W) 0.20 (149) 0.33 (246) 0.20 (149) 0.5 (373)
External Static Pressure, in wg. (mm) N/A 0.50 (13) N/A 0.50 (13)
Unit Refrigerant Charge, oz. (kg) 134 (3.8) 134 (3.8) 213 (6.0) 213 (6.0)
Unit Operating Weight, lb. (kg) 200 (91) 230 (104) 241 (109) 240 (109)
Free-Cooling Coil Option Net Capacity Data - kW (Btuh) using 45°F EWT
80°F DB, 62.8°F WB (26.7°C
DB, 17.1°C WB) 38%RH
Total 7.10 (24,200) 9.50 (32,400)
Sensible 6.60 (22,600) 9.05 (30,800)
75°F DB, 61°F WB (23.9°C
DB, 16.1°C WB) 45%RH
Total 6.15 (20,900) 8.20 (28,000)
Sensible 5.55 (18,900) 7.60 (25,900)
72°F DB, 60°F WB (22.2°C
DB, 15.5°C WB) 50%RH
Total 5.55 (18,900) 7.45 (25,400)
Sensible 4.85 (16,600) 6.70 (22,900)
Flow Rate, GPM (l/m) 4.5 (17.1) 5.9 (22.4)
Pressure Drop, ft. water (kPa) 5.6 (16.7) 9.1 (27.2)
Free-Cooling Coil - Copper Tube/Aluminum Fin
Face Area, ft
2
(m
2
) 3.1 (0.28) 3.1 (0.28)
Coil Rows 3 3
Max Face Velocity, fpm (m/s) 294 (1.5) 294 (1.5)
Internal Fluid Volume, gal (l) 2.0 (7.6) 2.0 (7.6)
Water supply/return connections, in (mm) OD 7/8 (22.2) 7/8 (22.2)
The net capacity data has fan motor heat factored in for all ratings and the entering air conditions of 75°F (23.9°C), 45%RH, is the standard rating
condition for ASHRAE 127-2007. All capacities are nominal values; actual performance will be ±5%.
Table 6.1 Air-cooled data, 60Hz (continued)
Evaporator Model MMD35E or MMD35K
Condensing Unit Type
PFH - Outdoor MCD - Indoor
DX Evaporator- Net Capacity Data - kW (Btuh) @ High Speed CFM
80°F DB, 62.8°F WB (26.7°C DB,
17.1°C WB) 38%RH
Total 9.95 (34,000) 9.50 (32,400)
Sensible 9.40 (32,100) 9.15 (31,300)
Table 6.2 Air-cooled data, 50Hz
Vertiv | Liebert Mini-Mate2—2 and 3 ton Technical Data Manual | 18
