Vertiv Liebert Mini-Mate2 MMD24E User Manual

Evaporator Model MMD35E or MMD35K
Condensing Unit Type
PFH - Outdoor MCD - Indoor
75°F DB, 61°F WB (23.9°C DB,
16.1°C WB) 45%RH
Total 9.60 (32,700) 9.10 (31,100)
Sensible 8.35 (28,500) 8.15 (27,800)
72°F DB, 60°F WB (22.2°C DB,
15.5°C WB) 50%RH
Total 9.35 (31,900) 8.90 (30,400)
Sensible 7.70 (26,200) 7.45 (25,500)
Fan Data - Evaporator
CFM (CMH) - High Speed 1250 (2124)
CFM (CMH) - Low Speed 1000 (1699)
Fan Motor HP (W) 0.5 (0.38)
External Static Pressure, in (mm) water gauge 0.3 (8)
Evaporator Coil - Copper Tube/Aluminum Fin
Face Area, ft
2
(m
2
) 3.1 (0.29)
Coil Rows 3
Max Face Velocity, fmp (m/s) 394 (2.0)
Unit Refrigerant Charge, oz. (kg) 7 (0.20)
Unit Operating Weight, lb (kg) 225 (102)
Electric Reheat Capacity (Includes Fan Motor)-kW (Btuh)
Input Voltage 220-1-50 5.3 (18090)
Input Voltage 380-3-50 7.3 (24900)
SCR Reheat Capacity (Includes Fan Motor)-kW (Btuh)
Input Voltage 220-1-50 8.7 (29700)
Input Voltage 380-3-50 10.3 (35100)
Humidifier Data - Steam Generator Type
Steam capacity lb/hr (kg/hr) 4.3 (2.0)
Electrical Input Power, kW 1.5
Evaporator Connection Sizes
Liquid line Diameter - Aeroquip Coupling Size 3/8" - #6 Female
Suction Line Diameter - Aeroquip Coupling Size 7/8" - #11 Female
Humidifier Supply 1/4" OD Copper Compression Fitting
Evaporator/Condensate Drain 3/4" NPT-Female
MERV 8 Filter, External Filter Box, qty (1), Nom. Size, in. (mm) 4x20x20 (102x508x508)
MERV 8 Filter, Air Distribution Plenum, qty (1), Nom. Size, in. (mm) 4x16x25 (102x406x635)
Condensing Unit Model Number
PFH036A-_L7 MCD35AL_H7
Condensing Unit Rating Conditions 95°F (35°C) Ambient
Coil Face Area, ft
2
(m
2
) 7.7 (0.72) 4.6 (0.43)
Rows of Coil
2 3
CMF (CMH) 2500 (4248) 1430 (2429)
Motor, Hp (W) 0.20 (149) 0.5 (373)
Table 6.2 Air-cooled data, 50Hz (continued)
Vertiv | Liebert Mini-Mate2—2 and 3 ton Technical Data Manual | 19
