Evaporator Model MMD35E or MMD35K
Condensing Unit Fluid
Water-Cooled Glycol-Cooled
DX Evaporator- Net Capacity Data - kW (Btuh) @ High Speed CFM
80°F DB, 62.8°F WB (26.7°C DB,
17.1°C WB) 38%RH
Total 11.3 (38,700) 9.20 (31,400)
Sensible 10.1 (34,400) 9.00 (30,700)
75°F DB, 61°F WB (23.9°C DB,
16.1°C WB) 45%RH
Total 11.0 (37,400) 8.80 (30,100)
Sensible 9.00 (30,700) 8.00 (27,300)
72°F DB, 60°F WB (22.2°C DB,
15.5°C WB) 50%RH
Total 10.7 (36,600) 8.60 (29,400)
Sensible 8.30 (28,400) 7.35 (25,100)
Fan Data - Evaporator
CFM (CMH), High Speed 1250 (2124)
CFM (CMH), Low Speed
1000 (1699)
Fan Motor HP (W) 0.5 (0.38)
External Static Pressure, in (mm) water gauge 0.3 (8)
Evaporator Coil - Copper Tube/Aluminum Fin
Face Area, ft
2
(m
2
) 3.1 (0.29)
Coil Rows 3
Max Face Velocity, fpm (m/s) 394 (2.0)
Unit Refrigerant Charge, oz. (kg) 7 (0.20)
Unit Operating Weight, lb (kg) 225 (102)
Electric Reheat Capacity (Includes Fan Motor)-kW (Btuh)
Input Voltage 220-1-50 5.3 (18090)
Input Voltage 380-3-50 7.3 (24900)
SCR Reheat Capacity (Includes Fan Motor)-kW (Btuh)
Input Voltage 220-1-50 8.7 (29700)
Input Voltage 380-3-50 10.3 (35100)
Humidifier Data - Steam Generator Type
Steam capacity - lbs/hr (kg/hr) 4.3 (2.0)
Electrical Input Power, kW 1.5
Evaporator Connection Sizes
Liquid line Diameter - Aeroquip Coupling Size 3/8" - #6 Female
Suction Line Diameter - Aeroquip Coupling Size 7/8" - #11 Female
Humidifier Supply 1/4" OD Copper Compression Fitting
Evaporator/Condensate Drain 3/4" NPT-Female
MERV 8 Filter, External Filter Box, qty (1), Nom. Size, in. (mm) 4x20x20 (102x508x508)
MERV 8 Filter, Air Distribution Plenum, qty (1), Nom. Size, in. (mm) 4x16x25 (102x406x635)
Condensing Unit Model Number MCD37W
Condenser Fluid Requirements 85°F (29.4°C) EWT 110°F (43.3°C) EGT - 40% PG
THR - kW (Btuh) @ 75F/45%RH 14.0 (47,800) 13.2 (44,900)
Table 7.2 Water/glycol data, 50Hz
Vertiv | Liebert Mini-Mate2—2 and 3 ton Technical Data Manual | 31
