Table 2 Suggested minimum input wire size data
Input
Voltage kVA
Units with Transformers Transformerless Units
Input
FLA
Input
OPD
Suggested Feeder
Wire Size (AWG)
Input
FLA
Input
OPD
Suggested Feeder
Wire Size (AWG)
208V
15 43 60 6 42 60 6
30871062 831062
50 145 200 000 139 175 00
75 215 295 350 kcmil 208 295 350 kcmil
100 286 400 (2) 000* 277 350 (2) 00*
125 358 432 (2) 0000* 347 432 (2) 0000*
150 427 600 (2) 350 kcmil* 416 600 (2) 350 kcmil*
240V
15 38 50 8
—— —
30 75 100 2
50 125 170 00
75 186 250 250 kcmil
100 248 340 (2) 00*
125 310 400 (2) 000*
150 370 480 (2) 250 kcmil*
380V
15 24 30 10 23 30 10
30 47 59 6 46 59 6
50 79 100 2 76 100 3
75 117 150 0 114 150 0
100 157 200 000 152 200 000
125 196 250 0000 190 250 250 kcmil
150 234 295 350 kcmil 228 295 350 kcmil
200 312 400 (2) 000* 304 400 (2) 000*
225 351 432 (2) 0000* 342 432 (2) 0000*
400V
15 23 30 10 23 30 10
304559643596
50 75 100 2 72 90 2
75 112 150 0 108 150 0
100 149 200 000 144 200 000
125 186 250 250 kcmil 180 225 0000
150 223 295 350 kcmil 217 295 350 kcmil
200297400(2) 000*289400(2) 000*
225 334 432 (2) 0000* 325 432 (2) 0000*
415V
15 22 30 10 21 30 10
304359642596
50 72 100 2 70 100 3
75 108 150 0 104 150 0
100 143 200 000 139 175 00
125 179 225 0000 174 225 0000
150 214 295 350 kcmil 209 295 350 kcmil
200 285 400 (2) 000* 278 350 (2) 00*
225 321 432 (2) 0000* 313 432 (2) 000*
