Vertiv Liebert PPC - Figure 1 Typical Cabinet and Floor Planning Dimensions, Sidecar

Vertiv | Liebert
®
PPC
™
User Manual | Rev. 6 | 03/18 | 3
Figure 1 Typical cabinet and floor planning dimensions, sidecar
18"
(457mm)
1-14"
(32mm)
30"
(762mm)
23-7/8"
(733 mm)
1/2"
(13mm)
Unit Base
Outline
Floor Pedestals
Available from 6"-19"
(152mm to 483mm)
9/16" (14mm)
Dia. Holes
2-1/4"
(57mm)
2-1/4"
(57mm)
2-1/4"
(57mm)
3/4"
(19mm)
3/4"
(19mm)
6"
(152mm)
6" (152mm)
2"
(50mm)
4"
(102mm)
18" (457 mm)
10"
(254 mm)
30" (762mm)
12"
(305mm)
22"
(559mm)
7"
(178mm)
20"
(508mm )
Overall
Dimension
18"
(457mm)
Unit Base
Pedestal
Footprint
Shaded areas indicate
recommended clearance
of 42" (1067mm) at front
and one other side for
service access.
Clearance of 6"
(152mm) below unit is
recommended for
cooling airflow and
cable exit .
Clearance of 18"
(457mm) above unit is
recommended for
cooling airflow .
Cutout area for
cable exit and
cooling airflow .
77"
(1959mm)
32"
(813 mm)
1"
(25.4mm)
30"
(762 mm)
Unit Base
Optional Floor
Pedestals
Footprint and Floor
Cutout Dimensions
Cabinet Dimensions
The Liebert EXC weighs 300 lb. (136kg)
