Vertiv | +24 VDC Power System User Manual (Section 6013) | Rev. G
174
Figure 19: Replacing List RD and RE Shunt POD Circuit Card
REAR VIEW OF LIST RD
(COVER REMOVED)
1
2
3
4
SHUNT MONITORING (SHUNT POD)
CIRCUIT CARD (PART NO. 501981)
Connector J1
