To View Measurement Parameters
Procedure
1. With "SYSTEM OK" being displayed on the MCA Interface Pad, press and release the FUNCTION SET
ENTER pushbutton.
or
With "## ALARMS ACTIVE" being displayed on the MCA Interface Pad, press and release the
FUNCTION SET ENTER pushbutton. Repeatedly press and release the FUNCTION SELECT DOWN
arrow pushbutton until "FUNCTION MENU" is displayed. Press and release the FUNCTION SET ENTER
pushbutton.
2. "MEASUREMENT MENU" is displayed. Press and release the FUNCTION SET ENTER pushbutton. Refer
to the MEASUREMENT MENUS in "Navigating the MCA" for additional information.
Viewing System Current Capacity
Procedure
1. With "SYSTEM OK" being displayed on the MCA Interface Pad, press and release the FUNCTION SET
ENTER pushbutton.
or
With "## ALARMS ACTIVE" being displayed on the MCA Interface Pad, press and release the
FUNCTION SET ENTER pushbutton. Repeatedly press and release the FUNCTION SELECT DOWN
arrow pushbutton until "FUNCTION MENU" is displayed. Press and release the FUNCTION SET ENTER
pushbutton.
2. Repeatedly press and release the FUNCTION SELECT DOWN arrow pushbutton until "ADJUSTMENT
MENU" is displayed.
3. Press and release the FUNCTION SET ENTER pushbutton.
4. "ADJUST SYSTEM" is displayed. Press and release the FUNCTION SET ENTER pushbutton.
5. Repeatedly press and release the FUNCTION SELECT DOWN arrow pushbutton until "100% Curr:
####A" is displayed. This is the current capacity of the system derived from the combined current
capacities of all installed Rectifier Modules.
6. To return to the beginning of the MCA Logic Tree, press and release the FUNCTION SET YES (+) and
NO (-) pushbuttons simultaneously.
