Vertiv | +24 VDC Power System User Manual (Section 6013) | Rev. G
NOTE!
If "AUTO EQ MUL = ##" is displayed, the system is already set for Automatic Equalize. In this
case, you can proceed with steps 5) through 8) to change the current setting, or proceed with step 9) if
no changes are required.
NOTE!
If "END AUTO ##.##HR" is displayed, the system is already set for Automatic Equalize, and an
Automatic Equalize is in progress. In this case, you can proceed with steps 5) through 8) to cancel the
Automatic Equalize in progress and change the current setting, or proceed with step 9) to proceed with
the Automatic Equalize in progress and make no changes.
5. Press and release the ALARM CUTOFF and FUNCTION SET ENTER pushbuttons simultaneously. The
"AUTO EQ MUL =" portion of the display flashes.
6. Press the FUNCTION SET YES (+) or FUNCTION SET NO (-) pushbutton until the desired value is
displayed, then release the pushbutton. Note that as you scroll below 1, "AUTO EQ DISABLED" is
displayed. Scroll back up to redisplay "AUTO EQ MUL =".
7. Press and release the ALARM CUTOFF and FUNCTION SET ENTER pushbuttons simultaneously.
8. “ARE YOU SURE? +_” is displayed. Press and release the FUNCTION SET YES (+) pushbutton.
9. Press and release the FUNCTION SET YES (+) and NO (-) pushbuttons simultaneously, to return to the
beginning of the MCA menu tree.
Placing the System into Test/Equalize Mode:
The MCA automatically does this for the conditions as
previously described.
The MCA automatically does this for the conditions as previously described.
NOTE!
Navigating to "END AUTO ##.##HR" of the MCA Configure Menu displays the hours remaining
in an automatic equalize period, if active.
NOTE!
Auto Equalize is canceled and the system is placed in the float mode if any of the following
occurs.
• Manually placing the system in the float mode by navigating to and activating "SET FLOAT MODE"
menu item in the MCA Function Menu.
• Resetting the "AUTO EQ MUL = ##" value in the MCA Configure Menu when "END AUTO ##.##HR" is
being displayed, as described in the previous procedure
• Applying an external test/equalize signal.
Method 4 (External Test/Equalize) Procedure
In this method, a user (or external equipment) places the system in the test/equalize mode by applying an
external signal to the system. The system returns to the float mode when the external signal is removed. This
method overrides the other three methods.
Placing the System into Test/Equalize Mode:
Apply system ground to the system's external test/equalize
terminal.
Remove system ground from the test/equalize terminal.
