VESDA VESDA-E VEP-A00 - Page 93

VESDA-EVEP-A00-P Product Guide
www.xtralis.com 87
4. Disconnect the chamber loom from the connector labeled J3 (Figure7-14).
Figure7-14: Disconnect Chamber Loom
5. Remove the chamber from the detector base (Figure7-15).
Figure7-15: Remove the Chamber from the detector base
