03_09
Tyres (03_09)
Periodically check the inflation pressure of each tyre (when cold).
Tyres are fitted with wear indicators; tyres should be replaced as soon as these indi-
cators become visible on the tyre tread. Also check that the tyres do not show signs
of splitting at the sides or irregular tread wear; If this occurs, go to an authorised work-
shop or at least a workshop adequately equipped to remove and refit tyres.
CAUTION
TYRE PRESSURE SHOULD BE CHECKED WHEN TYRES ARE COLD.INCOR-
RECT TYRE PRESSURE CAUSES ABNORMAL TYRE WEAR AND MAKES RID-
ING DANGEROUS.
TYRES MUST BE REPLACED WHEN THE TREAD REACHES THE WEAR LIMITS
SET FORTH BY LAW.
TYRES
Front tyre Tubeless, 110/70 - 11'' 45L
Rear tyre Tubeless, 120/70 - 10'' 54L
TYRE INFLATION PRESSURE
Front tyre pressure 1.6 bar
Rear tyre pressure (with
passenger)
2.0 bar (2.3 bar)
48
