Instrument panel bulb Type: Incandescent
Power: 12V - 2W
Quantity: 3
03_24
03_25
Front light group (03_24, 03_25, 03_26, 03_27, 03_28)
To access the headlight bulbs, remove the front of the handlebar cover, as follows:
- Remove the front cover as described in paragraph "Opening cases".
- Remove the rear-view mirrors as described in the paragraph "rear-view mirrors".
- Undo the front screw «B» and the two rear ones «A» that holding the handlebar
cover.
62
