VEHICLE SPECIFICATIONS
Chassis Stamped plate body with welded
structural reinforcements.
Front suspension Single arm with helical spring and
single double-acting hydraulic
shock absorber.
Rear suspension Double-acting shock absorber,
adjustable to four positions at
preloading.
Front brake Ø 200-mm disc brake with
hydraulic control activated by
handlebar right-side lever.
Rear brake Ø 110-mm drum brake with
mechanical control activated by
handlebar left-side lever.
Wheel rim type Light alloy wheel rims.
Front wheel rim 11'' x 2.50
Rear wheel rim 10'' x 3.00
Front tyre Tubeless, 110/70 - 11'' 45L
Rear tyre Tubeless, 120/70 - 10'' 54L
Front tyre pressure 1.6 bar
Rear tyre pressure (with
passenger)
2.0 bar (2.3 bar)
Kerb weight 114 kg ± 5 kg
Maximum weight allowed 264 kg
Battery Sealed 12V/6Ah
79
