Hub oil level (03_08)
Check the presence of oil in the hub, according to the regular controls shown in the
table of the scheduled maintenance.
WARNING
FOR THE REGULAR CHECK OF THE HUB OIL LEVEL SHOWN IN THE SCHED-
ULED MAINTENANCE TABLE, CONTACT AN Authorised Service Centre.
FOR THE CONTROLS OF THE HUB OIL LEVEL THAT ARE NOT PREDETER-
MINED BY THE SCHEDULED MAINTENANCE TABLE, OPERATE AS DESCRI-
BED.
03_08
LEVEL CHECK
- Park the vehicle on level ground and centre stand.
- Undo the screw «A» and by inserting punch, check the presence of oil that must be
below the lower edge of the loading hole.
- With a cloth carefully clean the transmission crankcase.
WARNING
THE FUNCTION OF THE HUB WITH INSUFFICIENT HUB LUBRICATION OR WITH
CONTAMINATED OR IMPROPER LUBRICANTS ACCELERATES THE WEAR
AND TEAR OF THE MOVING PARTS AND CAN CAUSE SERIOUS DAMAGE.
Characteristic
Hub oil
44
