Quantity: 5
Instrument panel lighting bulbs Type: All glass
Power: 12V 1.2W
Quantity: 4
Front light group (03_23, 03_24, 03_25, 03_26)
To reach the headlight bulbs proceed as follows:
- Undo the two screws «A» that are supporting the unit. Retrieve the nut «B» from the
rear screw.
- Undo the two screws «C», remove the front frame and pull the headlight assembly
parabola out.
To replace the high-/low-beam headlight bulb:
- Disconnect the connector, disengage the tab and pull the bulb «D» out.
To replace the tail light bulb:
- Pull the rubber bulb holder «E» out from its seat.
- Take hold of the lamp and pull it out.
N.B.
IF MISTING IS NOTICED ON THE INSIDE OF THE HEADLAMP GLASS, THIS
DOES NOT INDICATE A FAULT AND IS ATTRIBUTABLE TO HUMIDITY AND/OR
TO LOW TEMPERATURES.
THE PHENOMENON SHOULD QUICKLY DISAPPEAR WHEN THE LIGHT IS
SWITCHED ON.
58
