VEVOR MCS1000 - Technical Parameter

- 9 -
TECHNICAL PARAMETER
Voltage
230 V / 50 Hz
110 V / 60 Hz
Motor power
350W
Spindle speeds
885/1245/1715/2425RPM
Max. turning diamater
Ø 350 mm
Spindle diameter
Ø 22
Spindle thread
M18
Distance between centers
970mm
Tailostock spindle travel
10 mm
Taper in Tail stock Spindle
MT1
Weight
N.W：23Kg; G.W：28.2Kg
Package Size
1545×300×435mm
The general information given in this specification is not binding.
Know Your Wood Lathe: (Fig. 1 )
1. ON/OFF SWITCH
Device to turn the wood lathe power on or off.
2. BELT AND PULLEY COVER
Cover for belt and pulley. Open this cover to reach the belt and pulley when
changing the speed of drive center.
3. DRIVE CENTER
Holds workpiece for turning jobs.
4. BED RAILS
Rails for moving tailstock and toolrest.
5. TOOL REST
Stand holds tool when turning workpiece.
6. TOOL REST LOCK KNOB
Lock knob for height adjustment of tool rest.
7. TAIL STOCK ASSEMBLY
Works with drive center to hold workpiece for turning jobs
