VEVOR MCS1000 - Explosionszeichnung; Explosion Drawing

- 31 -
EXPLOSIONSZEICHNUNG / EXPLOSION DRAWING
INDEX NO
DESCRIPTION
SIZE
QTY
1
Lock handle knob
2
2
Lock handle
2
3
Clamp
1
4
Lock knob
1
5
Tool rest holder
1
6
Bolt
(M14x70)
2
7
Bolt
(M6x10)
4
8
Support bar
1
9
Tool rest
1
10
Center
1
11
Bearing
6201
1
12
Tail stock spindle
1
13
Screw
(M18)
1
14
Tail stock
1
15
Hand wheel
1
16
Hand wheel bar
1
17
Bed rail
2
18
Nut
(M8)
4
19
Spring washer
8
12
20
Washer
8
18
21
Supporter
1
22
Face plate
1
23
Bolt
(M8x55)
4
24
Drive center
1
25
Driving spindle
1
26
Bolt
(M4x10)
2
27
Screw
(M8x16)
10
28
Bearing washer
2
29
Bearing
6204
1
