d. The grounding wire should be held in green-yellow.
e. A damaged cable has to be exchanged immediately!
f. Check, whether the feeding voltage and the Hz comply to the required
values of the machine. A deviation of feeding voltage of ±5% is
allowed.
g. After connecting, check the right running direction!
h. Make sure that a possible extension cord is in good condition and
suitable for the transmission of power. An undersized cord reduces the
transmission of power and heats up.
ADJUSTING BELT TENSION
The lathe is packed with belt installed. However, it will need a adjustment
prior to using.
1. Disconnect the lathe from power souce.
2. Loosen and remove the hex bolt with adjustable wrench. (as figure 1)
3. Press down on the belt with hand.The belt should move 1/2” when set
properly. (as figure 2)
