BIOS Setup
41
SuperIO Device
Press Enter to enter the sub-menu and the following screen appears:
Onboard Serial Port 1/2
Set the base I/O port address and IRQ for the onboard serial port A /
serial port B. Selecting
Auto
allows BIOS to automatically determine the
correct base I/O port address. Settings:
Port Settings
1 Disabled 3F8/IRQ4 2F8/IRQ3 3E8/IRQ4 2E8/IRQ3 Auto
2 Disabled 3F8/IRQ4 2F8/IRQ3 3E8/IRQ4 2E8/IRQ3 Auto
Onboard Parallel Port
This specifies the I/O port address and IRQ of the onboard parallel port.
Settings:
Disabled, 378/IRQ7, 278/IRQ5, 3BC/IRQ7
Parallel Port Mode
Set the parallel port mode. To operate the onboard parallel port as
Standard Parallel Port, choose
SPP
. To operate the onboard parallel port
in the EPP mode, choose
EPP
. By choosing
ECP
, the onboard parallel
port will operate in ECP mode. Choosing
ECP + EPP
will allow the
onboard parallel port to support both the ECP and EPP modes
simultaneously. Settings:
SPP, EPP, ECP, ECP + EPP
