Replacing Fasteners
• To replace the fastener
− Start with the white prong
− Note the “keying” notch feature
− Tilt the prong to insert into the heatsink leg.
− Holding the white prong without bending it, push the black pin on from the bottom until you hear
a single “click”
Damaged. Attempts to
straighten not recommended
Tilt to remove
Re
lacement
Tilt to insert
To Next Page
