44
3-11 Thermal Throttling Option
CMOS Setup Utility – Copyright(C) 1984-2004 Award Software
Miscellaneous Control
Item Help
CPU Thermal-Throttling Disabled
CPU Thermal-Throttling Temp 70
CPU Thermal-Throttling Duty 87.50%
Beep Alarm Enabled
Menu Level >
↑↓→←
Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Optimized Defaults F7:Standard Defaults
CPU Thermal Throttling Temp
This item allows you to activate the CPU Thermal Throttling function when the CPU
temperature is over the value which you set to low down the CPU temperature when at high
workload to protect processor from damage or accidental shutdown.
3-12 Power User Overclock Settings
Phoenix – AwardBIOS CMOS Setup Utility
Power User Overclock Settings
Item Help
Current FSB Frequency 200MHZ
Current DRAM Frequency 200MHZ
CPU Voltage at Next Boot Default
CPU Ratio at next boot Default
MEM Clock at Next Boot Auto
CPU Clock at next Boot 200MHZ
CPU Vcore 7-Shift Normal(Default)
VDIMM Select 2.55V (Default)
NBchip 1.2V Select 1.20 (Default)
SBChip 1.5V Select 1.50 (Default)
Menu Level >
↑↓→←
Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Optimized Defaults F7:Standard Defaults
CPU/DRAM Clock at next Boot is
This item allows you change the CPU Host /DRAM clock for overclock demand.
When the CPU
Host clock is over the CPU default value BIOS will auto disabled Bi-Turbo function
.
CPU Vcore 7-Shift
This item allows you select the CPU Vcore Voltage xx% more than the standard value, by
this function for the precise over-clocking for extra demanding of performance.
VDIMM Select
This item allows you to select 2.5V of the DDR Module. The choice are: 2.55V, 2.6V, 2.65V,
2.7V.
