IPScan Probe 600 User’s Guide
14
2.2.2.1. ARP check Interval [Online](min)/[Offline](min)
It is to define the intervals for IPScan Probe 600 to send out ARP packets to online or offline IP
within the managing segment for the update.
Step1 For Online IP, select 1, [ARP check Interval [Online](min)] from [Ethernet Port No] menu.
System setting. Select a number : 1
Step2 Define interval from 0 to 0-1440 minutes. Default interval is 5 minutes.
Enter the data forwarding interval between 0-1440 minutes : 5
Step3 For Offline IP, Select 2. [ARP check Interval [Offline](min)] from [Ethernet Port No] menu.
System setting. Select a number : 2
Step4 Define interval from 0 to 0-1440 minutes. Default interval is 10 minutes.
Enter the data forwarding interval between 0-1440 minutes : 10
The above configuration means that the Online IP addresses of managed IP range will be
checked every 5 minutes and Offline IP addresses will be checked every 10 minutes.
2.2.2.2. Off range Interval (min)
It is to define how often the probe should forward off range IP being detected within the
managing segment to the server.
Step1
Select 3. [Off range Interval] from [Ethernet Port No] menu.
System setting. Select a number : 3
Step2
Define interval from 0 to 1440 minutes and press [Enter].
¾ -1 : Do not forward detected off range IP event to the server.
¾ 0 : Send off range IP event only once for the same IP after the probe is connected. If there
are other off range IP events, the probe send it once again.
Enter the Off range send interval between -1~1440 minutes.
If this value is -1, This event will be ignored.
Enter the value : 0
