IPScan Probe 600 User’s Guide
17
2.3. LAN
LAN is a must configuration for IPScan Probe 600 to be connected to the network. .
Step1
Select 2. [LAN] from [Main Menu].
Step2
Below screen will appear. Choose Ethernet Port number you wish to define, and then
define the network configuration.
LAN Ethernet Port 1
0. Ethernet Port 1
1. Ethernet Port 2
2. Ethernet Port 3
3. Ethernet Port 4
4. Ethernet Port 5
5. Ethernet Port 6
0. Main Menu
1. IP
2. Netmask
3. Gateway
4. Master Server IP
5. Secondary Server IP
6. Connection Port
7. VLAN ID
8. Master Port
9. Speed
0. Main Menu
MAC Address
Serial No
[192.168.101.20]
[255.255.255.0]
[192.168.101.1]
[192.168.101.10]
[0.0.0.0]
[30001]
[0]
[0]
[Auto]
[00:03:2e-05:02:77]
[VSxxxxxxxxxxxxxx]
No Menu Description
1 IP
2 Netmask Subnet mask
3 Gateway Gateway address.
4 Master Server IP IP address of the master (primary) IPScan Server.
5 Secondary Server
IP
IP address of secondary IPScan Server. This is necessary if you are using
the server redundancy feature.
If you have configured master and secondary server, the probe will
constantly check for master server’s status. If the master server is
disconnected or failed to respond, the probe will automatically be
connected to the secondary server without data loss. Probe will
check the Server if there is an abnormal situation such as
communication failure between the probe and the server. Thus the
probe will not check the Master server without any situation changes
even if the probe is being connected to the Secondary server.
When the Master Server is recovered, the Secondary Server sends
a induction massage to connect to the Master Server to all probes
within managed range.
6 Connection Port The TCP Port for the communication between IPScan Server and Probe.
If you change the port number, you should change it in the [Server
Configuration] of the IPScan Server Monitor.
7 VLAN ID VLAN ID of the segment where the probe is located at. If VLAN is not
relevant, enter ‘0’. The default value is ‘0’.
8 Master Port Define Ethernet Port to communicate with IPScan Server
** The detailed information is on the next page [2.3.1. Master Port].
Note
To Next Page
