Viavito setry - Page 32

32
www.viavito.com
No. DESCRIPTION SPECIFICATION QTY
J-6 Cross Screw ST4.2*20L
K Fixing Plate for Magent Set 1
K-1 Fixing Plate for Magnet 4
K-2 Spring D1.0*55L
K-3 Nylon Nut M6*1*6T 1
K-4 Flat Washer D13*D6.5*1.0T 1
K-5 Nylon Washer D6*D19*1.5T 2
K-6 Nut M6*1*6T 2
K-7 Bolt M6*65L 2
K-8 Nylon Nut M8*1.25*8T 2
K-9 Bolt M8*52L,thread 15MM
K-10 Magnet 39.5*10*25 1
K-11 Plate for Magnet 40*3*3 2
L Fixing plate for idle wheel set 1
L-1 Fixing plate for idle wheel
L-2 Spring D3*D17*59L 1
L-3 Plastic Flat Washer D10*D24*0.4T 1
L-4 Flat Washer D50*D10*3.0T 1
L-5 Bolt M8*1.25*30L,8.8grade 2
L-6 Flat Washer D30*D8.2*3.0T 1
L-7 Nylon Nut M10*1.5*10T 1
L-8 Idle Wheel D42xD38x24 1
L-9 Nut M8*1.25*6T 1
L-10 Nylon Nut M8*1.25*8T 2
M Belt Wheel Set 1
M-1 Waved Washer D17*D22*0.3T 1
M2 Flat Washer D23*D17.2*1.5T 1
