33
www.viavito.com
No. DESCRIPTION SPECIFICATION QTY
M-3 C-Clip ST4.2*20L 2
M-4 Belt 1118L PJ5 1
M-5 Belt Wheel D280*19 1
M-6 Crank Axle 1
M-7 Round Magnet M02 1
M-8 Bolt M6*1.0*15L-8.8grade 4
M-9 Nylon Nut M6x1.0x6T 4
N Hardware Board
N-1 Square neck Bolt M8x1.25x75L,8.8grade 4
N-2 Domed Nut M8x1.25x15L,8.8grade 4
N-3 Spring Washer D15.4xD8.2x2T 18
N-4 Curved Washer D22xD8.5x1.5T 14
N-5 Allen Bolt M8x1.25x20L ,8.8grade 12
N-6 Coned Washer D14*D8*4 2
N-7 Club Knob D40*M6*12 4
N-8 Flat Washer D14xD6.5x0.8T 4
N-9 Square Neck Bolt M6*1*45L 4
N-10 Waved Washer D26*D19.5*0.3T 2
N-11 Screw Cover D29*21(M8) 2
N-12 Bolt M8x1.25x25 2
N-13 Flat Washer D25xD8.5x2T 2
N-14 Screw Cover D28*17(M10) 2
N-15 Screw Cover D30*17(M12) 2
N-16 Pedal Axle Cover D30*11L 2
N-17 Round Screw M8*1.25*16L 2
0 Protective Cover 114*76*43 1
P Pedal Assemble Set
