No. DESCRIPTION SPECIFICATION QTY
P-1 Pedal welding tube
P-2 Square cap 30*60*15 1
P-3 Nylon nut M10*1.5*10T 4
P-4 Flat washer D20*D11*2.0T
P-5 Bushing D19.15x(D25.6x32)xL(17+3) 1
P-6 Bushing D29*D11.9*9T 1
P-7 C-clip D21.5xD17.5x1.2T 2
P-8 Joint 2
P-9 Flat washer D24*D13.5*2.5T 2
P-10 Ladder bolt M10*1.5*58L 8.8grade 2
P-11 Pedal axle D19*128.5L
Q Moveable supporting tube
sets
1
Q-1 Moveable support tube 2
Q-2 Bushing D19.15x(D25.6x32)xL(17+3) 1
Q-3 Front pedal axle D19x72L
Q-4 C-clip D21.5xD17.5x1.2T 1
Q-5 Waved washer D26*D19.5*0.3T 1
R Adaptor Output:9V,500mA 1
S Axle D19x334.5(M8x1.25) 2
T Fly Wheel Set 1
T-1 Fly Wheel D260x77L 1
T-2 Fly Wheel Axle D10x120L(3/8"-26UNF) 1
T-3 Fixing Ring D13*D10*1.9T 1
T-4 Nut D9.5x4T(3/8"-26UNFx4T) 2
T-5 Anti-loosen Nut 3/8"-26UNF*6.5T 1
T-6 Nut D9.5x5T(3/8"-26UNFx5T) 1
T-7 Bearing #6000ZZ 1
