APPENDIX A-2 Manual 0-5141
CUTMASTER 42
APPENDIX 2: SL40 TORCH PIN-OUT DIAGRAM
A. Hand Torch Pin-Out Diagram
1
2
3
4
5
6
7
8
5
6
7
8
1
2
3
4
Pilot
Pilot
6 - Open
7 - Open
8 - Open
5 - Open
Negative /
Plasma
6 - Open
7 - Open
5 - Open
2 - Torch Jumper input
3 - Torch/PIP
switch input
4 - Torch/PIP
switch input
1 - Torch Jumper input
4 - Green /
Torch/PIP switches
1&2- Shorted
Jumper
3 - Yellow /
Torch/PIP switches
Negative /
Plasma
Cutmaster 42 Female Torch Receptacle
Front View
8 - Ground
ATC Male Connector
Front View
Art # A-11809
